"AH" Block

Why use “AH” Lightweight Insulation Blocks?

Our “AH” Lightweight Insulation Block is made from recycled LCD glass which is environmentally-friendly and do not contain any toxic by-products such as asbestos and formaldehyde. It is a 100% green product and is certified non-combustible, having attained a 132 minutes fire rating by TUV SUD PSB Pte Ltd, Singapore. Our product has undergone an acoustics lab test, obtaining a noise reduction coefficient (NRC) rating of 0.45 and a sound reduction index (STC) of 34 dBa. “AH” Lightweight Insulation Block reduces up to 50% of the average weight of partition walls, ceiling blocks and fire doors. It is a good heat insulator and the indoor temperature difference between its external walls can potentially achieve an average of more than 15 degrees. The blocks do not produce any toxic smoke in any unforeseen cases of burning. It is used for residential buildings, laboratories, petrochemical industries, marine industries, boiler rooms and warehouses.

Our lightweight solid blocks combine the advantages of “skeleton + panel + lightweight insulation block” for all kinds of walls and ceilings and comprise a systematic assembling method.

Concerned over construction time, on-site waste or the environmental and physical-sustainability of some blocks?

You will enjoy the following benefits with “AH” Lightweight Insulation Blocks

Shorter Construction Time & Higher Work Efficiency

  • The work rate is about 20㎡ per person per day. This is higher than the work rate for red brick walls, light grout walls and RC walls.

On-site Waste Reduction

  • "AH" Lightweight Insulation Blocks involve dry construction, keeping your construction site clean and dry, instead of being wet and dirty.

Environment-friendly Building Materials

  • Innovative Type II Green LCD Glass Recycling that improves Construction Quality, Material Quality and creates a Sustainable Service for your buildings and the environment

Easy To Achieve Quality Control

  • Standardisation and a Systematic assembly mode make quality control easy

Higher Physical Performance

  • Easy to install
  • Superior structural and physical properties will not be affected by dampness or moisture

Noise-proof Performance

  • 42 dB sound barrier, meeting most demands for a quiet environment

No Harmful Ingredients

  • Our blocks do not contain asbestos or formaldehyde, which are harmful to the human body
  • Reduces the exposure to asbestos or formaldehyde during the construction process

Applicable to all types of partition walls and ceiling projects

  • Applicable to light steel buildings
  • Offices; Commercial Spaces; Schools
  • Collective Apartment Buildings; Apartments
  • Integrated Housing; Leisure Residential Buildings
  • Rooms; Suites; Villas
  • Factories; Warehouses
  • Partition for Box Compartments
  • Shopping Centres; Department Stores; Restaurants
  • Hospitals; Clinics
  • Libraries; Nursing Homes
  • Hotels; Bed & Breakfasts; Farmhouses
  • High-Tech Electronic Plants
  • Any area and building requiring fire-proofing, shock-proofing, water-proofing, heat insulation or sound insulation qualities

COMPARISON OF COMMONLY-USED PARTITION WALLS

Wall Type RC WALL 1/2B BRICK WALL WHITE BRICK WALL BLOCK PRE-EAST WALL (CERAMIC BOARD) LIGHT PARTITION GROUT WALL LIGHT PARTITION HOLLOW WALL “AH” LIGHTWEIGHT SOLID WALL
Wall Thickness 10~15 cm 12~15 cm 12cm 8~10 cm Longer than 7.7cm 7.7~10 cm 7.7~11 cm
Wall Weight Over 350kg/m² Over 260kg/m² 85kg/m² 85kg/m² 80kg/m² 37kg/m² Over 45kg/m²
Sound Insulation 40 dB 38 dB 38 dB 40 dB 40 dB 30~38 dB 42 dB
Nail Hanging Load Good Good Accessories needed for reinforcement Good Poor (high uncertainty) Poor Over 75kg
Work Speed Slow Slow Average Average Average Fast 20/ m²/man/day
Piping Difficult Difficult Pipe drilling required Pipe drilling required Embedded water and electricity pipes required Embedded water and electricity pipes required Convenient
Fire Aging 1~2 hrs 1~2 hrs 1~2 hrs 1~2 hrs 1~2 hrs Over 1 hr Over 2 hrs
Work Method Wet Wet Dry Semi wet Semi wet Dry Dry
Waste Site pollution Site pollution Site pollution Site pollution Site pollution Site pollution Product waste can be fully recycled

OUR “AH” LIGHTWEIGHT INSULATION BLOCK MEASURE

40cm x 50cm x 65mm ± 1.5mm (5 pieces / m2)

“AH” Lightweight Insulation Block

They are also available in the following sizes:
40cm x 50cm x 92mm ± 1.5mm (5 pieces / m2)
40cm x 50cm x 75mm ± 1.5mm (5 pieces / m2)
